Tracked Radial Stacker

Name: Tracked Radial Stacker
Brand: SANTO
Rating: 5 (295 reviews)

The tracked radial stacker has strong material storage management capability. Its horizontal stacking section is in the form of a ladder fan, which can effectively improve the material storage capacity of the material yard. Essentially, the tracked radial stacker has packaged all the advantages of a mobile radial stacker and that of a tracked stacker into one product, which is generally used after mobile crushing and screening plant.

Capacity: 300-700 TPH
Conveying Length: 20-24 m
Stacking Height: 9.4-10.7 m

Get A Price Chat Online

Tracked Radial Stacker Structure

Tracked Radial Stacker structure

01Radial Axle

Powered Radial Axle

Hydraulic wheel drives sweep the discharge end through an arc and can support automatic stockpile patterns.

02Crawler Chassis

Easy to Move

The crawler base moves the complete machine around the site without relying on a separate towing vehicle.

03Conveyor Lift

Adjustable Discharge Height

Hydraulic conveyor elevation matches the required pile height while limiting unnecessary material drop.

04Adjustable Feed Height

Hydraulic Adjustment Feed Height

Hydraulic adjustment for variable feed height reduces impact and provides optimal material transfer.

05Turn 360°

Radial Movement Design

Superior slewing performance, 360° slewing allows large-scale material storage.

Tracked Radial Stacker Advantages

Hydraulic Radial Drive

Swinging radial axle complete with hydraulic wheel drives, optional fully automatic stockpiling system.

Easy Transport

Transports easily via low loader or packed in container for shipping with minimal reassembly required.

360° Slewing

Superior slewing performance, 360° slewing allows large-scale material storage.

Adjustable Feed Height

Hydraulic adjustment for variable feed height reduces impact and provides optimal material transfer.

Adjustable Stockpiling Height

The height of the tracked radial stacker conveyor can be adjusted to match the height of the stockpile to be stacked by hydraulic system.

Increased Plant Productivity

Dramatically increase crusher / screener plant productivity and efficiency.

Reduced Double Handling

Eliminate double handling of material with wheel loader.

Tracked Radial Stacker Technical Parameters

Model	Belt Width	Length	Stacking Height	Stockpile Volume	Capacity	Weight
TS820R	800 mm / 31.5 in	20 m / 65 ft	9.4 m / 30.8 ft	1,405.8 m³	300 T/H	15 t
TS824R	800 mm / 31.5 in	24 m / 80 ft	10.7 m / 35.1 ft	2,086.2 m³	300 T/H	16 t
TS1020R	1000 mm / 39.3 in	20 m / 65 ft	9.4 m / 30.8 ft	1,405.8 m³	500 T/H	16 t
TS1024R	1000 mm / 39.3 in	24 m / 80 ft	10.7 m / 35.1 ft	2,086.2 m³	500 T/H	17 t
TS1220R	1200 mm / 47.2 in	20 m / 65 ft	9.4 m / 30.8 ft	1,405.8 m³	700 T/H	18 t
TS1224R	1200 mm / 47.23 in	24 m / 80 ft	10.7 m / 35.1 ft	2,086.2 m³	700 T/H	19 t

*The above data are for reference only. For specific information, please refer to the actual product and product manual. Unless otherwise specified, the right to interpret the data involved in this website belongs to SANTO.

*SANTO can provide customized equipment tailored to your specific needs. Contact us anytime.
